10KG Load Cell Wide Bar
The 10KG Load Cell Wide Bar is a compact, highly sensitive weight sensor designed for precise measurement of force or load. Built with an aluminum alloy body and four strain gauges in a Wheatstone bridge configuration, it provides an accurate analog output signal corresponding to applied weight.
This module is widely used with microcontrollers like Arduino, ESP32, or Raspberry Pi, in combination with an HX711 amplifier module for digital conversion of the analog signal.
⚙️ Key Features
-
Capacity: 0–10 KG
-
Type: Straight/Wide Bar Load Cell
-
Material: High-quality aluminum alloy
-
Bridge Type: 4-wire Wheatstone bridge
-
Output: Analog signal (mV/V)
-
Dimensions: 80 mm × 12.6 mm × 12.6 mm (approx.)
-
Operating Voltage: 5V (with HX711 amplifier)
-
Accuracy: High sensitivity and linear output
-
Temperature Range: -40°C to +85°C
-
Mounting: Dual-hole design for secure installation
📐 Technical Specifications
| Parameter | Value |
|---|---|
| Model | Load Cell 10KG Wide Bar |
| Material | Aluminum Alloy |
| Rated Load | 10KG |
| Bridge Configuration | 4-Wire Wheatstone Bridge |
| Output Type | Analog (mV/V) |
| Excitation Voltage | 5V DC (Recommended) |
| Accuracy | ±0.02% FS |
| Operating Temp | -40°C to +85°C |
| Dimensions | 80 × 12.6 × 12.6 mm |
| Wire Color Code | Red: E+, Black: E−, Green: S+, White: S− |
🧰 Applications
-
Digital Weighing Scales and Kitchen Scales
-
Robotics Weight Detection Systems
-
Arduino Projects with HX711 amplifier
-
IoT & Smart Automation Systems
-
Industrial Load Monitoring
-
DIY Electronic Projects – use with Electronics Components for smart designs
⚠️ Precautions
-
Do not exceed 10KG maximum load to prevent permanent strain damage.
-
Use with a stable Power Supply for accurate readings.
-
Avoid side or torsional forces on the load cell.
-
Calibrate using known reference weights for best accuracy.
-
Shield signal wires to reduce noise interference.
🧩 Recommended Accessories
-
HX711 Amplifier Module – for analog-to-digital signal conversion.
-
Arduino Boards – for reading and processing load values.
-
Tools and Accessories – for mounting, calibration, and assembly.
▶️ YouTube Tutorial Video
Watch: How to Use a 10KG Load Cell with HX711 & Arduino
This video shows how to wire, calibrate, and code the Load Cell with Arduino and HX711 for weight measurement projects.
📝 Product Summary
The 10KG Load Cell Wide Bar Sensor is a precise and durable load-sensing element ideal for Arduino and IoT applications. With a lightweight aluminum body, high sensitivity, and Wheatstone bridge design, it’s perfect for building digital weighing scales, smart automation systems, or force measurement instruments.
Enhance accuracy and performance by pairing it with an HX711 amplifier and Arduino controller.
